High Speed V Groove Cutter Machine Multiple Size CNC V Grooving Machine

Ask Lasest Price
Brand Name :	SUBIERUI
Model Number :	GSVM
Certification :	ISO9001 CE
Price :	Negotiate
Payment Terms :	T/T
Supply Ability :	30 sets per mouth
Delivery Time :	10-30days

Add to Cart

Product Details
Company Profile

High Speed V Groove Cutter Machine Multiple Size CNC V Grooving Machine

High-Speed V Groover Machine for Door Industry with Multiple Size Options

The GSTM v grooving machine tool rest uses 6 knives to process the "V" groove, so the cutting amount is evenly distributed to reduce the deformation of the workpiece. The micro cooling system can be selected to prolong the service life of the tool and reduce the production cost; The universal tool clamping mounting surface can meet the clamping requirements of various tools. The white steel tool and alloy tool are interchangeable; The tool carrier transfer device uses a heavy-duty linear guide rail, so the precision is high.

Customization and modification of equipment

Consulting for new equipment is not the only solution when there is a need to adjust process flow, change materials or improve the utilization of existing capacity in production. Our engineers can work with you to analyze and assess the current situation of your equipment, and combine your needs and desires to develop a complete set of solutions for you, from small-scale equipment customization to equipment modification. We will work with you to develop personalized maintenance schemes for all projects according to your technical needs so as to avoid costly out-of-chapter downtime, ensure the service life of equipment and improve the value of equipment itself. Take advantage of these strengths to maximize process and investment safety. Of course, equipment manufactured by other manufacturers is no exception.

Intelligent obstacle avoidance of presser feet

The system automatically calculates the cutting position of each step of the workpiece, fixes the presser foot to automatically reserve the cutting space for the tool holder, and realizes intelligent obstacle avoidance.

Name		Parameter	Unit
Max. Width of metal sheet		1500	mm
Max. Length of metal sheet		4000	mm
Max. thickness(Stainless steel)		6	mm
Min. Thickness of metal sheet		0.4	mm
Min.distance of the V from edge		10	mm
Max. cutting speed of X axis		120	m/min
Max .return speed of X axis		120	m/min
Max.distance of Y axis		1250	mm
Resolution in Y axis		0.001	mm
Repeated positioning accuracy		±0.01	mm
Resolution in z axis		0.001	mm
Repeated positioning accuracy		±0.01	mm
Motor power	X axis	5.5	kW
	Y.Z axis	1.0
Overall dimension	Length	5700	mm
	Width	2600
	Height	2000
