Horizontal Cnc V Cutting Machine V Groove Machine For Metal Signage

Ask Lasest Price
Brand Name :	JM
Model Number :	GSHM
Certification :	ISO9001,CE
Price :	Negotiate
Payment Terms :	T/T
Supply Ability :	30 sets per mouth
Delivery Time :	10-30days

Add to Cart

Product Details
Company Profile

Horizontal Cnc V Cutting Machine V Groove Machine For Metal Signage

Precise Horizontal V Cutting Machine for Signage Production with Hydraulic Drive

The tool holder (b) of GSHM v grooving machine is equipped with four alloy cutters to process the V-shape groove, so the cutting amount is evenly distributed to reduce the deformation of the machined parts. The micro cooling system can be selected to prolong the service life of the tool and reduce the production cost; The universal tool clamping mounting surface can meet the clamping requirements of various tools. The white steel tool and alloy tool are interchangeable; The tool carrier transfer device uses grinding grade ball screw and heavy-duty linear guide rail, so it has high accuracy.

Customization and modification of equipment

Consulting for new equipment is not the only solution when there is a need to adjust process flow, change materials or improve the utilization of existing capacity in production. Our engineers can work with you to analyze and assess the current situation of your equipment, and combine your needs and desires to develop a complete set of solutions for you, from small-scale equipment customization to equipment modification. We will work with you to develop personalized maintenance schemes for all projects according to your technical needs so as to avoid costly out-of-chapter downtime, ensure the service life of equipment and improve the value of equipment itself. Take advantage of these strengths to maximize process and investment safety. Of course, equipment manufactured by other manufacturers is no exception.

Tool holder self-lubricating system

The tool holder of the equipment is equipped with self-lubricating system, which can move up and down at the same time and self-lubricate the tool holder, greatly reducing the internal losses of the tool holder and improving the service life of the tool holder.

No.	Name		Parameter	Unit
1	Max. Width of metal sheet		1250	mm
2	Max. Length of metal sheet		4000	mm
3	Max. thickness(Stainless steel)		5	mm
4	Min. Thickness of metal sheet		0.4	mm
5	Min.distance of the V from edge		8	mm
6	Max. cutting speed of X axis		120	m/min
7	Max .return speed of the X axis		120	m/min
8	Max.distance of Y axis		1250	mm
9	Resolution in Y1 axis		0.001	mm
10	Repeated positioning accuracy		±0.01	mm
11	Resolution in z axis		0.001	mm
12	Repeated positioning accuracy		±0.01	mm
13	Motor power	X axis	5.5	kW
13	Motor power	Y1.Y2.Z axis	1.0	kW
14	Overall dimension	Length	5900	mm
		Width	2000
		Height	1550
