Hydraulic Horizontal V Cutting Machine For Anti Skateboard V Groover Machine

Ask Lasest Price
Brand Name :	JM
Model Number :	GSHM
Certification :	ISO9001,CE
Price :	Negotiate
Payment Terms :	T/T
Supply Ability :	30 sets per mouth
Delivery Time :	10-30days

Add to Cart

Product Details
Company Profile

Hydraulic Horizontal V Cutting Machine For Anti Skateboard V Groover Machine

Horizontal V Grooving Machine for Anti-Skateboard Metal Edges with Hydraulic Drive

Automatic calculation of inner and outer diameters
The system can automatically calculate the slot distance according to the input size and the selected inner or outer diameter function. Reduce operation difficulty and labor cost.

Customization and modification of equipment

Consulting for new equipment is not the only solution when there is a need to adjust process flow, change materials or improve the utilization of existing capacity in production. Our engineers can work with you to analyze and assess the current situation of your equipment, and combine your needs and desires to develop a complete set of solutions for you, from small-scale equipment customization to equipment modification. We will work with you to develop personalized maintenance schemes for all projects according to your technical needs so as to avoid costly out-of-chapter downtime, ensure the service life of equipment and improve the value of equipment itself. Take advantage of these strengths to maximize process and investment safety. Of course, equipment manufactured by other manufacturers is no exception.

Bending effect display

Based on the input data, the system can display the bending effect diagram in real time to avoid the loss of raw material caused by input errors and input omissions.

No.	Name		Parameter	Unit
1	Max. Width of metal sheet		1250	mm
2	Max. Length of metal sheet		4000	mm
3	Max. thickness(Stainless steel)		5	mm
4	Min. Thickness of metal sheet		0.4	mm
5	Min.distance of the V from edge		8	mm
6	Max. cutting speed of X axis		120	m/min
7	Max .return speed of the X axis		120	m/min
8	Max.distance of Y axis		1250	mm
9	Resolution in Y1 axis		0.001	mm
10	Repeated positioning accuracy		±0.01	mm
11	Resolution in z axis		0.001	mm
12	Repeated positioning accuracy		±0.01	mm
13	Motor power	X axis	5.5	kW
13	Motor power	Y1.Y2.Z axis	1.0	kW
14	Overall dimension	Length	5900	mm
		Width	2000
		Height	1550
