    Hydraulic Sheet Metal Grooving Machine Stainless Steel V Groove Cutter Machine

    Ask Lasest Price
    Brand Name : SUBIERUI
    Model Number : GSVM
    Certification : ISO9001,CE
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 30sets per mouth
    Delivery Time : 7-25 days
    • Product Details
    • Company Profile

    Hydraulic Sheet Metal Grooving Machine Stainless Steel V Groove Cutter Machine

    Hydraulic Sheet Metal Grooving Machine for Stainless Steel Decoration Projects


    Professional team
    SUBIERUI not only has excellent equipment, but also can provide considerate after-sales service. From the planning and starting of the project, to the production tracking and operation training, to the equipment maintenance, the supply and maintenance of spare parts, we can provide you with a full range of services.


    Spare parts Service
    The equipment and units in SUBIERUI have a long service life. The original parts can be found in our spare parts warehouse regardless of the year the equipment was shipped. Our technical service personnel are familiar with all manufacturers' equipment, from the initial assembly of new equipment to the selection of spare parts, and can provide you with professional assistance, even from other manufacturers..
    Multiple auxiliary presser feet
    The number of auxiliary presser feet is large and the distribution is scientific. Multiple auxiliary presser feet in two directions are hydraulically controlled, and the workpiece clamping is more stable and reliable.
    No.NameParameterUnit
    1Max. Width of metal sheet1250mm
    2Max. Length of metal sheet4000mm
    3Max. thickness(Stainless steel)6mm
    4Min. Thickness of metal sheet0.4mm
    5Min.distance of the V from edge10mm
    6Max. cutting speed of X axis120m/min
    7Max .return speed of the X axis120m/min
    8Max.distance of Y axis1250mm
    9Resolution in Y1 axis0.001mm
    10Repeated positioning accuracy±0.01mm
    11Resolution in z axis0.001mm
    12Repeated positioning accuracy±0.01mm
    13Motor powerX axis5.5kW
    Y.Z axis1.0
    14Overall dimensionLength5700mm
    Width2350
    Height2000

    Hydraulic Sheet Metal Grooving Machine Stainless Steel V Groove Cutter Machine
